British Admiralty Nautical Chart Q6114 Maritime Security Chart West Africa including Gulf of Guinea

One of a series of new Maritime Security Charts. These charts contain security related information for the area of that chart, including details of reporting schemes and regional contacts, as well as general security advice. It is to be used in conjunction with standard nautical charts and publications.

Chart Q6114

Main Chart Details

• Chart Title: Maritime Security Chart West Africa including Gulf of Guinea
• Publication Date: 10/04/2014
• Latest Edition date: 28/02/2019
• Chart Size: 1115 x 704 (mm)

Chart Panel Details

• Panel Name Maritime Security Chart West Africa including Gulf of Guinea
• Area Name West Africa including Gulf of Guinea
• Natural Scale 8500000
• North Limit 23° 00′.00N
• East Limit 18° 30′.00E
• South Limit 25° 00′.00S
• West Limit 25° 30′.00W

• Panel Name Gulf of Guinea
• Natural Scale 5200000
• North Limit 10° 00′.00N
• East Limit 11° 00′.00E
• South Limit 0° 30′.00S
• West Limit 16° 00′.00W

Co-ordinates given are usually those of the four extremities of the chart. In many cases not all the area within will be fully charted*.Customers should check that the chart meets their requirements by viewing the chart image (where available).Mariners should always use the largest scale navigational chart available.

*Reasons may include

• Continuation of coverage of a small part outside the main area of chart coverage e.g a river.
• Inset plans and the chart title block and notes also take up space, therefore geographical information cannot be shown in this area.
• A need to refer to larger scale of chart, such waters are often “blued out” to avoid excessive maintenance work applying numerous NM corrections to an area of the small scale chart where the navigator will be using a larger scale chart.
• Coverage is better served from a different chart because of typical routeings.
